Avigilon 1.0C-H4IRPTZ-DP45-WP User Manual

4. Fasten the pendant wall mount to the mounting surface.
5. Tighten the wall mount screws to secure the wall mount to the wall.
6. Connect the safety lanyard from inside the wall mount to the anchor on the PTZ camera.
Installing the NPT Mount
Note: This procedure requires a 1-1/2” NPT-female to NPT-female pipe adapter. It is recommended
that the NPT adapter be mounted to a 1-1/2” conduit pipe.
Installing the NPT Mount 8

Avigilon 1.0C-H4IRPTZ-DP45-WP Specifications

General

Brand	Avigilon
Model	1.0C-H4IRPTZ-DP45-WP
Category	Security Camera
Language	English
