4. Yellow (RI_1)— Digital Input, Relay 1. The input voltage must be below 0.7V to register as a low input.
The input voltage should not exceed 5V when high.
5. Orange (RI_2)— Digital Input, Relay 2
6. Light Green (RI_3)— Digital Input, Relay 3
7. Brown (RI_4) Digital Input, Relay 4
8. Purple (RO+)— +5V power output from camera. For the maximum allowable current, see Specifications
on page29.
9. Blue (RO_1) Digital Output,
10. Green (RO_2) Digital Output
11. Pink (Reserved) Reserved Wire, do not connect.
12. Red (DC) Auxiliary Power Wire, accepts DC and AC power.
13. Black (DC) Auxiliary Power Wire, accepts DC and AC power.
l
1 External relay power supply
l
2 Optional 24 V AC (RMS) or 24 V DC Aux. power supply
Connecting to Power and External Devices 21
