Housing Pendant mount
Finish Powder coat, RAL 9003
Tilt -20° to 90°, 300° / second max.
Pan 360°, endless, 300° / second max.
Electrical
Power
Consumption
75 W max
105 VA with 24 V AC power
Power Source V DC: 24 V +/- 10%
V AC: 24 Vrms +/- 10%, 50 or 60Hz
PoE: 95 W PoE (POE-INJ2-95W)
Power Connector Wire leads
RTC Backup
Battery
3V manganese lithium
Environmental
Operating
Temperature
-40°C to +60°C (-40 °F to 140 °F) with external power or 95W PoE
Storage
Temperature
-10 °C to +70 °C (14 °F to 158 °F)
Humidity 0-95% non-condensing
Certifications
Certifications UL, cUL, CE, ROHS, WEEE, RCM
Safety UL 62368-1, CSA 62368-1, IEC/EN 62368-1
Environmental IK10 Impact Rating (camera body only)
IEC 60529 IP66 Weather Rating
IEC/UL/CSA 60950-22
Electromagnetic
Emissions
FCC Part 15 Subpart B Class B
IC ICES-003 Class B
EN 55032 Class B
EN 61000-6-3
EN 61000-3-2
EN 61000-3-3
Electromagnetic
Immunity
EN 55024
EN 61000-6-1
Specifications 30
