l If using ½” or ¾ exterior conduit, install a conduit plate to an external conduit adaptor then slide
the mounting adaptor over the conduit and plate assembly. Ensure the plate is compatible with the
type of conduit used.
If you are installing the outdoor model (H4SL-DO), you may need to cut off part of the rubber
gasket on the mounting adapter to make room for the plate.
Mounting the Dome Camera Using the Side Cable Entry 11
