Avision FF-2010B - 1.3 Rear View

User’s Manual
1-4
Position
Adjuster
Slide the adjuster inward to make the
Output Tray in a flat position.
Output Tray
Open to collect the document after
scanned.
Paperweight
Used to hold down a stack of output
paper.
Paper Stopper
Adjust to the length of the documents
to prevent them from falling apart.
1.3 Rear View
Item
Description
LAN Port
Used to connect to network.
Power Jack
Connect the AC adapter to the scanner.
USB Port
Connect to your computer.
Kensington
Security Slot
Attach to a lock to secure the scanner.
LAN Port
Power Jack
USB Port
Security Slot
