H2/3

VIOLET/BLACK (-) 200mA PROGRAMMABLE (-) AUX 1 OUTPUT

This wire provides 200 mA programmable output whenever the transmitter but-

tons controlling Aux 1 channel is pressed.

Warning! Never use this wire to drive anything

but a relay or a low-current input, supplied

output is only 200mA. Connecting directly to

a solenoid, motor, or other high-current device

will cause the module to fail.

H2/4

GREEN/WHITE FACTORY ALARM REARM OUTPUT

This wire sends a negative pulse every time the remote start shuts down or when

the doors are locked. This can be used to pulse the arm wire of the vehicle’s fac-

tory anti-theft device. Use a relay to send a (-) or (+) pulse to the arm wire.

H2/5

GRAY/BLACK (-) DIESEL WAIT TO START BULB INPUT

Connect this wire to the wire in the vehicle that sends the signal to turn on the

WAIT-TO-START bulb in the dashboard. In most diesels the wire is negative

(ground turns on the bulb) and the GRAY/BLACK wire can be directly connected

to the wire in the vehicle. If the vehicle uses a positive wire (12V to turn on the

bulb) a relay must be used to change the polarity.

Note: A 1-amp diode must be installed in line on the factory wire between the

wait-to-start indicator and the ECM. (See the following diagramS for details).
