53
© 2008 Directed Electronics. All rights reserved.
Table of zones
When using the Diagnostic functions, use the Table of Zones to see which input
has triggered the system. It is also helpful in deciding which input to use when
connecting optional sensors and switches.
Zone No. Trigger Type
Input Description
1
Trunk Input BLUE (H1/7)
2
Multiplexed Shock Sensor Input Mux BLUE wire.
3
Door Trigger GREEN (H1/8) and VIOLET
(H1/6).
4
Multiplexed Shock Sensor Input Mux GREEN wire
5
Ignition
Yellow ribbon harness wire
6
Hood Brake Trigger GRAY on the 6-pin shutdown har-
ness
