27
© 2008 Directed Electronics. All rights reserved.
➤ Horn, (H4) Aux 3 harness
H4/1
ORANGE/BLACK 200 mA PROGRAMMABLE (-) AUX 3 OUTPUT
This wire provides a (-) 200mA output whenever the transmitter button(s) control-
ling Aux 3 is pressed. (see also the Feature Descriptions section and revious Aux
2 description)
Warning! Never use this wire to drive anything
but a relay or a low-current input, supplied out-
put is only 200mA. Connecting directly to a
solenoid, motor, or other high-current device
will cause the module to fail.
H4/2
BROWN 200mA (-) HORN OUTPUT
This wire provides a (-) 200mA output to the horn when programmed.
Warning! Never use this wire to drive anything
but a relay or a low-current input, supplied out-
put is only 200mA. Connecting directly to a
solenoid, motor, or other high-current device
will cause the module to fail.
