AVMATRIX PVS0615 User Manual

Multiview Output Format
1080p 60
Return Loss
>15dB 5MHz~3GHz
Signal Amplitude
800mV±10% (SDI/HDMI/DVI/VGA)
Impedance
SDI: 75Ω; HDMI: 100Ω
DC Offset
0V±0.5V
Audio
Audio Input
1×TRS(L/R), 50 Ω
Audio Output
1×TRS(L/R), 50 Ω; 3.5mm Earphone×1, 100 Ω
Others
LAN
RJ45
SD Card Slot
1
Power
DC 12V, 2.75A
Consumption
<33W
Operation Temperature
-20℃~60℃
Storage Temperature
-30℃~70℃
Operation Humidity
20%~70%RH
Storage Humidity
0%~90%RH
Dimension
375×271.5×43.7mm
Weight
3.8Kg
Warranty
2 Year Limited
Accessories
Accessories
1×Power Supply (DC12V 5A), 1×User Manual
