AVMATRIX PVS0615 User Manual

2) Earphone
Press LISTEN button and use a 3.5mm earphone to monitor an assigned audio, PGM audio as the
default. Press LISTEN button cyclically to assign one channel audio as the audio source.
Transition Effects
MIX Transition
Pressing the MIX button selects a basic A/B Dissolve for the next transition. When button LED
turns on it is active. Then use T-Bar or AUTO to operate the transition. The MIX transition effect as below
WIPE Transition
WIPE is a transition from one source to another and is achieved by replacing the current source by
another source. Press the WIPE button and the LED turns on then it is active. There are total 9
WIPE selections wiping start from different directions. Such as if choosing , then use T-Bar or
AUTO to operate the transition, the WIPE effect as following:

AVMATRIX PVS0615 Specifications

General

Brand	AVMATRIX
Model	PVS0615
Category	Switch
Language	English
