AVMATRIX VS0601U User Manual

6
5. OPERATION INSTRUCTION
5.1. Multiview Output Layout
PGM and PVW as Preview and Program displayed as following image. The level meter of PGM audio is
shown only in multiview. SDI/HDMI PGM out is without any overlays.
The following 6 windows come from the 6 input signals.
6
FADE
Fade transition effect
7
MIX
Mix transition effect
8
Wipe transition effect
9
PIP
Picture in Picture
10
FTB
Fade to Black, used for emergency
11
AUTO
Performs an automated switch between Program and Preview.
12
CUT
Performs a simple immediate switch between Program and Preview.
13
T-bar
T-bar Manual Transition
