AVMATRIX VS0601U - Interfaces; Rear Interfaces; Tally PIN Definition

3
2. INTERFACES
2.1. Rear Interfaces
2.2. Tally PIN Definition
PIN
Definition
PIN
Definition
11
PGM-IN1
6
PVW-IN1
12
PGM-IN2
7
PVW-IN2
13
PGM-IN3
8
PVW-IN3
14
PGM-IN4
9
PVW-IN4
15
PGM-IN5
10
PVW-IN5
3
PGM-IN6
4
PVW-IN6
5
GND
1
LAN (for update)
2
3.5mm AUDIO IN/ OUT
3
AUDIO OUT
4
AUDIO IN
5
HDMI PGM OUT
6
HDMI &SDI MULTIVEW OUT
7
SDI AUX OUT
7
SDI PGM OUT
8
SDI IN
9
HDMI IN
10
DC 12V
11
Power Switch
12
SDI AUX OUT(for PVW/PGM)
13
USB OUT (for live streaming)
14
GPIO (for tally)
