Avonic CM7 IP Series User Manual

Next to multicast, there is also unicast allowing you to stream video (via RTSP) to one single users IP address. For
more information read also Unicast, Multicast and Broadcast on the website.
Figure 21: WebGUI > VIDEO > Multicast Streaming
The recommended Multicast Streaming settings are listed below.
Stream Option Main Stream Sub Stream
Enable Mark checkbox to enable/ disable Mark checkbox to enable/ disable
Protocol Type RTP Multicast/ TS Multicast/ TS Unicast RTP/ TS Multicast/ TS Unicast
Address (multicast) 224.0.0.0~ 239.255.255.255 224.0.0.0~ 239.255.255.255
Address (unicast) Specify the IP address to which you want the Unicast stream pushed.
Port 4000 (default) 4002 (default)
Access Method rtp://224.1.2.3:4000 rtp://224.1.2.3:4002
Click SAVE to apply your settings. A small confirmation dialogue appears in the bottom right corner.
VIDEO - Camera Settings
Figure 22: WebGUI > VIDEO > Camera Settings
Execute the following steps to define your camera settings:
1. Use the Camera Settings tabs (outlined below) to change the OSD settings as if you are using the
remote control.
28
