Avonic CM7 IP Series User Manual

Camera Control Commands
All parameter values are in HEX
•
x = Camera Address
•
y = Socket Number
•
z = Camera Address + 8
Camera Control Commands
Command Function Command Packet Comments
Address Set Broadcast 88 30 01 FF Address setting
On 8x 01 04 00 02 FF Power ON
Off 8x 01 04 00 03 FF Power OFF
CAM_Power
Reboot 8x 0A 01 06 01 FF Reboot
Stop 8x 01 04 07 00 FF
Tele (Standard speed) 8x 01 04 07 02 FF
Wide (Standard speed) 8x 01 04 07 03 FF
Tele (Variable speed) 8x 01 04 07 2p FF
Wide (Variable speed) 8x 01 04 07 3p FF
p = 0(low speed) -F(high speed)
Direct 8x 01 04 47 0p 0q 0r 0s FF
CAM_Zoom
Zoom Wide ~ Tele 00 00 00 00 ~ 04 00 00 00 (PQRS)
pqrs(0-F): Zoom Position
Stop 8x 01 04 08 00 FF
Far (Standard speed) 8x 01 04 08 02 FF
Near (Standard speed) 8x 01 04 08 03 FF
Far (Variable speed) 8x 01 04 08 2p FF
Near (Variable speed) 8x 01 04 08 3p FF
p = 0(low) - F(high)
Direct Focus Position 8x 01 04 48 0p 0q 0r 0s FF min p = 0, q = 0, r = 0, s = 0 max
p = 0, q = 6, r = E, s =A
Auto Focus 8x 01 04 38 02 FF
Manual Focus 8x 01 04 38 03 FF
Auto/Manual 8x 01 04 38 10 FF
OnePush mode 8x 01 04 38 04 FF
OnePush trigger 8x 01 04 18 01 FF
AF On
AF Off
AF Toggle On/Off
CAM_Focus
Focus Near ~ Far Variable ~ 00 00 00 00 (PQRS) pqrs: Focus Position
Auto 8x 01 04 35 00 FF Normal Auto
Indoor mode 8x 01 04 35 01 FF Indoor mode
Outdoor mode 8x 01 04 35 02 FF Outdoor mode
OnePush mode 8x 01 04 35 03 FF One Push WB mode
OnePush trigger 8x 01 04 10 05 FF One Push WB Trigger
CAM_WB
Manual 8x 01 04 35 05 FF Manual Control mode
