APPENDIX E - DATASHEET (SPECIFICATIONS)
SPECIFICATIONS CM70-IP
Camera Input / Output Interface
Resolution Up to 1080p60 HDMI output 1.4
Video Systems 1920x1080/ 1280x720
p60/ 50/ 30/ 25/ 59.94/ 29.97
SDI output 3G-SDI, SMPTE 425M level A, 10-bit
YCbCr 4:2:2
Sensor 1/3” CMOS, 2.12mp, 16:9 USB Output USB 2.0 (max. 1080p30)
Shutter Auto, Manual, 1/25 ~1/10000 Network interface RJ45 100 Mbit
Scanning mode Progressive, Interlaced (not over IP) Control UVC, IR Remote, IP, Serial
Zoom/Aperture/Focal lenght 20x optical/ F1.8-F11/ 4.4-88.8 mm Serial communication RS232 mini DIN-8, RS485 2pin Phoenix
Minimal Illumination 0.05 LUX Serial control protocol VISCA over Serial, PELCO-P, PELCO-D
IP control protocol VISCA OVER IP, ONVIF, HTTP APIWhite Balance Auto, Manual, OnePush,
2400K-7100K in steps of 100K
Backlight Compensation supported
General Specifications
Digital Noise Reduction 2D & 3D DNR Input voltage 12V
Signal Noise Ratio >55 dB PoE PoE 12W (802.3af)
Horizontal FOV wide ~ tele 60.38° ~ 3.72° Power consumption 12W
Vertical FOV wide ~tele 35.80° ~ 2.14° Power supply 12V2A
Horizontal rotation -170° ~ +170° Power connector EIAJ-4 - Philmore 255 plug
Vertical rotation -30° ~ +90° Operating temperature -5°C ~ 40°C
Pan speed range 1.7 ~ 120°/s Storage temperature -20°C ~ 60°C
Tilt speed range 1.7 ~ 70°/s Operating humidity 20% ~ 95% non-condensing
H&V image flip supported Bottom fastening screw thread 1/4" 20 UNC
Number of presets 255 Color Black, White
Preset accuracy 0.1 Dimensions product wxhxd 133 x 180 x 153 mm excl. connectors
Weight product 1,6 kgs
IP features
Dimensions box 26 x 24 x 24 cm
Video coding standard H.265 / H.264 / MJPEG Weight box 2.4 kg
H.265 Profiles main
H.264 Profiles main, base high
Main stream resolution 1920x1080 / 1280x720
Included power adapter, remote control, RS232
cable, RS485 2-way Phoenix connector,
Balanced Audio, Line-In 5-way Phoenix
connector
Main stream max frame rate 60fps
Versions
Main stream bitrate 64 ~ 40960 Kbps Black CM70-IP-B
White CM70-IP-WSub stream resolution 320x180 / 320x240 / 640x360 / 1280x720 /
1920x1080
Sub stream max frame rate 30fps
Sub stream bitrate 64 ~ 40960 Kbps
Compliance
Video bitrate type Variable, Fixed Markings CE, FCC, cULus
Support protocols RTSP, RTMP,ONVIF, SRT, Multicast, Unicast Medical EN-IEC 60601-1-2 (2015) certified (class
A, home- and professional healthcare
environment)
Audio standard AAC / mp3 / G.711A
Audio bitrate 32, 64, 96, 128 Kbps
Audio sample rate 16, 32, 44.1, 48 Khz
Audio line in balanced audio line in via 5-way
Phoenix connector.
91
