Avonic CM7 IP Series User Manual

Video OSD
byAlpha 128
white rgb (255,255,255)
black rgb (0,0,0)
yellow rgb (255,255,0)
red rgb (255,0,0)
Time FontColor http://192.168.5.126/ajaxcom?szCmd={"SetEnv":{"VideoOsd":[{"stTime":
{"stFtColor":{"byAlpha":128,"byRed":255,"byGreen":255,"byBlue":0}},
"nChannel":0}]}}
blue rgb (0,0,255)
byAlpha 128
white rgb (255,255,255)
Title FontColor http://192.168.5.126/ajaxcom?szCmd={"SetEnv":{"VideoOsd":[{"stTitle":
{"stFtColor":{"byAlpha":128,"byRed":255,"byGreen":255,"byBlue":0}},
"nChannel":0}]}}
black rgb (0,0,0)
yellow rgb (255,255,0)
red rgb (255,0,0)
blue rgb (0,0,255)
OSD Offsetx pos Time: http://192.168.5.126/ajaxcom?szCmd={"SetEnv":{"VideoOsd":
[{"stTime":{"nXPos":9200},"nChannel":0}]}}
nXPos [0, 10000]
OSD Offsetx pos Title: http://192.168.5.126/ajaxcom?szCmd={"SetEnv":{"VideoOsd":[{"stTitle":
{"nXPos":9200},"nChannel":0}]}}
nXPos [0, 10000]
OSD Offsety pos Time: http://192.168.5.126/ajaxcom?szCmd={"SetEnv":{"VideoOsd":
[{"stTime":{"nYPos":1200},"nChannel":0}]}}
nYPos [0, 10000]
Title: http://192.168.5.126/ajaxcom?szCmd={"SetEnv":{"VideoOsd":[{"stTitle":
{"nYPos":1200},"nChannel":0}]}}
OSD Font Size
Get OSD font size parameters
Code http://192.168.5.126/ajaxcom?szCmd={"GetEnv":{"TTFFontSize":{"nChannel":-1}}}
Set video parameters
Code http://192.168.5.126/ajaxcom?szCmd={"SetEnv":{"TTFFontSize":{"nFontSize":[48,48],"bAutoSize":1}}}
Function Code Command Setting
bAutoSize 0: off,1: on
nFontSize [8,200]
Output Format
(Video) Output Format
Get video out parameters
Code http://192.168.5.126/ajaxcom?szCmd={"GetEnv":{"VideoOut":{"nChannel":-1}}}
Set video out parameters
Code http://192.168.5.126/ajaxcom?szCmd={"SetEnv":{"VideoOut":{"nNetMode":2,"emVoutFormat":9,"byFormatList":
[10,9,4,3,8,7,6,5,26,25,20,21,22,23,24]}}}
Function Code Command Setting
nNetMode:
default value 2, do not modify it
– HD output
– HD output + SD network
– SD output + HD network
85
