When the operator password is entered, will be shown on the status bar of the screen, and the main menu
is NOT allowed to access. The operator user level needs to be set in the main menu “SYSTEM” “TOOLS”.
To switch between these two user levels, click the current user level icon to switch to the key lock mode, and
move your mouse to show the password input keypad, and enter the password of the user level you want.
3.5 VGA Output Resolution Support
Users are allowed to change the resolution depending on their display monitor.
Right-click to display the main menu, and select “ADVANCED CONFIG” “DISPLAY”.
ADVANCED CONFIG
CAMERA
DE-INTERLACE OFF
DETECTION
FULL SCREEN DURATION 03
ALERT
QUAD SCREEN DURATION (For Selected Models Only) 03
NETWORK
DWELL SCREEN DURATION 03
DISPLAY
DISPLAY COVERT ON
RECORD
HDD DISPLAY MODE HDD SIZE
DEVICES
VIDEO OUTPUT (For Selected Models Only) BOTH
ALPHA BLENDING 200
VGA OUTPUT 1024 x 768
VGA DEINTERLACE (For Selected Models Only) ON
COMPOSITE DEINTERLACE (For Selected Models Only) ON
EXIT
Move to “VGA OUTPUT”, and select the VGA resolution you want. There are three options as follows:
1024 x 768 (default)
1280 x 1024
1600 x 1200
Note: For 4CH models, “VGA OUTPUT” appears only when “PRIORITY” is set to “DISPLAY FIRST”. For
details, please refer to “3.6 System Sources Reallocation (For 4CH Models Only)”.
Note: To have the best image quality on your LCD monitor, make sure (1) the selected DVR VGA output
resolution is supported by your monitor, and (2) the VGA output settings on both the LCD
monitor and DVR are consistent.
If the image is not positioned or scaled properly, please go to your monitor’s menu for
adjustment. For details, please refer to the user manual of your LCD monitor.
3.6 System Sources Reallocation (For 4CH Models Only)
Go to “QUICK START” “GENERAL”, and select “PRIORITY” to reallocate the system sources to live display,
and record.
There are three options for this function: RECORD FIRST / DISPLAY FIRST.
QUICK START
GENERAL
CHANNEL TITLE ON
TIME SETUP
EVENT STATUS ON
DATE DISPLAY ON
DCCS DISPLAY ON
MOUSE SENSITIVITY - ׀ ׀ ׀ ׀ ׀ ׀ ׀ ׀ ׀ +
PRIORITY (For 4CH Models Only) RECORD FIRST
RECORD CONFIG SETUP
EXIT
To Next Page
