A4 Examining Signal Transmission
When the DVR is powered on, right-click to display the main menu, and select “ADVANCED CONFIG” 
“DCCS”.
ADVANCED CONFIG
C A N E R A CH1 CH2 CH3
CH4
CH5
CH6
CH7
CH8
CH9
CH10
CH11 W X
DETECTION
DIAGNOSTIC START
ALERT
MENU SETUP
NETWORK
DISPLAY
RECORD
DEVICES
DCCS
DEVICE AVK523
IVS
CONNECTION OK
NOTIFY
EXIT
1) Make sure the model number of your DCCS camera is shown in “DEVICE”. If not, please check your camera
connection.
2) Select the channel which connects to your DCCS camera, and click “START” in “DIAGNOSTIC” to examine
the signal transmission between the DCCS camera and the DVR.
