TrueBrake Installation Manual v1.0 - November 2019
© Aeroxcraft Ltd 2019
AXC Logo is registered trademark of Aeroxcraft Ltd. Logitech the Logitech logo and other Logitech marks are owned by Logitech and may be
registered.
*Aeroxcraft Ltd will not be held responsible for any damage to your Logitech pedals or steering wheel.
Use a Phillips No.2 screwdriver to remove the 12 large
screws shown opposite.
Once all the screws are removed and safely put to one
side then you can remove the bottom cover to gain
access to the inside.
Take note of how the wiring loom is arranged and
attached to the plastic moulding.
