AXIOMTEK CAPA848 - 1.1 Features; 1.2 Specifications

CAPA848 Capa Board
2 Introduction
1.1 Features
 Intel
®
Celeron
®
dual core N2807 (1.58GHz)
 1 DDR3L SO-DIMM supports up to 8 GB memory capacity
 4 USB 2.0 ports
 4 COM ports
 2 PCI-Express Mini Card
 +12V only DC-in supported
 Wide operating temperature supported
1.2 Specifications
 CPU
 Intel
®
Celeron
®
dual core N2807 1.58GHz.
 Thermal Solution
 Passive.
 Operating Temperature
 -20°C~70°C.
 BIOS
 American Megatrends Inc. UEFI (Unified Extensible Firmware Interface) BIOS.
 16Mbit SPI Flash, DMI, Plug and Play.
 PXE Ethernet Boot ROM.
 System Memory
 One 204-pin unbuffered DDR3L SO-DIMM socket.
 Maximum up to 8GB DDR3L 1333MHz memory.
 Onboard Multi I/O
 Controller: Nuvoton NCT6106D.
 Serial Ports: Two ports for RS-232/422/485 and two ports for RS-232.
 Serial ATA
 One SATA-300 connector.
 mSATA supported (Optional).
 USB Interface
 Four USB ports with fuse protection and complies with USB Spec. Rev. 2.0.
 Display
 One 15-pin D-Sub as VGA connector.
 One 2x20-pin connector for 18/24-bit single/dual channel LVDS and one 8-pin
inverter connector. LVDS resolution is up to 1920x1200 in 24-bit dual channels.
 One HDMI.
