AXIS 205 Network Camera Installation
5
Example:
For Unix/Linux, enter the following: (note that you must be the root user and that the ping
length must be 408.)
Example (for Linux):
Note: In some Unix/Linux systems, the arp command can be located in a directory that is not
on the command path; e.g: /usr/sbin/arp
4. Now connect the power adapter to the camera and plug into your main power supply.
No more than 2 minutes should have elapsed since the ARP command was run. Text
similar to the following is then displayed in the window:
5. Press Ctrl+C to stop Ping. Ensure that the Power Indicator is permanently lit and that
the Network Indicator flashes intermittently. The IP address has now been set. You
should now also set the remaining network parameters from the camera’s setup tools.
Accessing the Camera from a Browser
Open a browser and type in the IP address used to install the camera, as shown in the
example below. This opens the Live View page, which shows live video from the camera,
and provides a link to the setup tools. See the online help for more information.
c:\WINNT>arp -s 192.168.0.125 00-40-8c-18-10-00
c:\WINNT>ping -l 408 -t 192.168.0.125
>arp -s 192.168.0.125 00:40:8c:18:10:00 temp
>ping -s 408 192.168.0.125
c:\WINNT>arp -s 192.168.0.125 00-40-8c-18-10-00
c:\WINNT>ping -l 408 -t 192.168.0.125
Pinging 192.168.0.125 with 408 bytes of data:
Request timed out.
Request timed out.
Request timed out.
Reply from 192.168.0.125: bytes=408 time<10ms TTL=64
Reply from 192.168.0.125: bytes=408 time<10ms TTL=64
