44
AXIS 210/210A/211/211A - System Options
Network - UPnP™
The cameras includes support for UPnP™, which is enabled by default. If also enabled on
your computer, the camera will automatically be detected and a new icon will be added to
“My Network Places.”
Note: UPnP must also be enabled on your Windows XP or ME computer. To do this, open the Control Panel from
the Start Menu and select Add/Remove Programs. Select Add/Remove Windows Components and open
the Networking Services section. Click Details and then select UPnP as the service to add.
Network - RTP / MPEG-4
These settings are for the IP addresses, port numbers, and Time-To-Live values to use for
media streams in the MPEG-4 format. Only certain IP addresses and port numbers should
be used for these streams. For more information, please see the online help.
Ports & Devices
I/O Ports - the pinout, interface support and the control and monitoring functions
provided by this connector are described in
The I/O Terminal Connector, on page 47.
LED Settings
The Status indicator LED on the front of the camera can be set to flash at a configurable
interval (or to not light up at all) whenever the unit is accessed. For a listing of all LED
behavior, see
page 8, or the online help.
Note: The LED does not flash when the stream is retrieved using MPEG-4 multicast.
Maintenance
• Restart - The camera is restarted without changing any of the settings. Use this method
if the unit is not behaving as expected.
• Restore - The unit is restarted and most current settings are reset to factory default val-
ues. The settings that will not be reset are as follows:
• the boot protocol (DHCP or static)
• the static IP address
• the default router
•the subnet mask
• the system time
•Default - The default button should be used with caution. Pressing this will return all of
the camera's settings (including the IP address) to the factory default values.
Upgrade Server - See Upgrading the Firmware, on page 54.
