Pagina 40 Guida all'installazione di AXIS 211M
Panoramica dell’hardware
Dimensioni
AxLxP = 44 x 88 x 172 mm (1,7" x 3,4" x 6,8")
Peso = 244 g (0,5 lb) (alimentatore non incluso)
Connettore
di alimentazione
Connettore
di rete
Connettore I/O
Cavo di controllo
obiettivo DC Iris
Levetta messa a fuoco
Indicatore di stato e
microfono interno
Levetta zoom (Tele/Wide)
Indicatore di alimentazione
Indicatore di rete
Numero di serie
Etichetta lato inferiore
Pannello posteriore
Pulsante Control
Ingresso audio
Uscita audio

Table of Contents

Other manuals for Axis 211M

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Axis 211M and is the answer not in the manual?

Axis 211M Specifications

General IconGeneral
Maximum resolution1280 x 1024 pixels
Camera shutter speed1/15000 - 1/4 s
Minimum illumination1 lx
Sensor typeCMOS
Progressive scanYes
Optical sensor size1/3 \
Focal length range3 - 8 mm
Power source typePoE
Power consumption (typical)5 W
Processor modelARTPEC-A
Flash memory8 MB
Internal memory64 MB
I/O ports1x RJ-45
Dimensions (WxDxH)44 x 88 x 172 mm
Power requirementsDC 7 - 20V
Resolution description1.3MP
Supported network protocolsIPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Operating temperature (T-T)0 - 45 °C
Operating relative humidity (H-H)20 - 80 %
Weight and Dimensions IconWeight and Dimensions
Weight244 g
