Page 8 AXIS 211M Installation Guide
AXIS Camera Management - multiple cameras/large installations
AXIS Camera Management can automatically discover multiple Axis devices, show
connection status, manage firmware upgrades and set IP addresses.
Automatic discovery
1. Check that the camera is connected to the network and that power has been applied.
2. Start AXIS Camera Management. When the AXIS 211M appears in the window, double-
click it to open the camera’s home page.
3. See page 9 for instructions on how to set the password.
Assign an IP address in a single device
1. Select AXIS 211M in AXIS Camera Management and click
the Assign IP button.
2. Select Assign the following IP address and enter the IP
the subnet mask and default router the device will use.
3. Click the OK button.
Assign IP addresses in multiple devices
AXIS Camera Management speeds up the process of assigning IP addresses to multiple
devices, by suggesting IP addresses from a specified range.
1. Select the devices you wish to configure (different models
can be selected) and click the Assign IP button.
2. Select Assign the following IP address range and enter
the range of IP addresses, the subnet mask and default
router the devices will use.
3. Click the OK button.

Table of Contents

Other manuals for Axis 211M

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Axis 211M and is the answer not in the manual?

Axis 211M Specifications

General IconGeneral
Maximum resolution1280 x 1024 pixels
Camera shutter speed1/15000 - 1/4 s
Minimum illumination1 lx
Sensor typeCMOS
Progressive scanYes
Optical sensor size1/3 \
Focal length range3 - 8 mm
Power source typePoE
Power consumption (typical)5 W
Processor modelARTPEC-A
Flash memory8 MB
Internal memory64 MB
I/O ports1x RJ-45
Dimensions (WxDxH)44 x 88 x 172 mm
Power requirementsDC 7 - 20V
Resolution description1.3MP
Supported network protocolsIPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Operating temperature (T-T)0 - 45 °C
Operating relative humidity (H-H)20 - 80 %
Weight and Dimensions IconWeight and Dimensions
Weight244 g
