AXIS 214 PTZ - Video & Image settings
5. Click Save.
6. Go to Setup > Video & Image and modify the parameters under Overlay Settings.
Overlay image requirements:
The height and width of the overlay image in
pixels must be exactly divisible by 4.
Overlay image requirements:
• The maximum overlay image size supported by the AXIS 214 PTZ is the same as the
maximum image resolution. See Technical Specifications,
on page 56.
• When a text overlay is also used, this reduces the amount of space available to the
overlay image. To keep the text readable at lower resolutions, the text overlay occupies
proportionally more and more space, i.e., 16 pixels in height at 640x480, 32 pixels at
320x240 and 64 pixels at 160x120.
• If the overlay is initially positioned so that part of it is outside the video image, it will
be relocated so that it appears over the video image, i.e. it is always the entire image
that is displayed.
Please see the online help for more information.
Image Formats Image Size
• Windows 24-bit BMP (full color)
• Windows 4-bit BMP (16 colors)
