AXIS 214 PTZ - Technical Specifications
Technical Specifications
Item Specification
Models • AXIS 214 PTZ 50Hz (PAL)
• AXIS 214 PTZ 60Hz (NTSC)
Video compression • Motion-JPEG. Snapshot JPEG images available. User-controlled
compression level.
• MPEG-4 Part2 (ISO/IEC 14496-2), Profiles: ASP and SP.
Resolutions 16 different resolutions up to 752x582 (PAL) and 752x480 (NTSC) via API,
5 selections via configuration web page.
Frame rates • Motion JPEG: Up to 25/30 (PAL/NTSC) frames second in all resolutions
• MPEG-4: Up to 25/30 fps at 2CIF
Video streaming • Simultaneous Motion JPEG and MPEG-4
• Controllable frame rate and bandwidth
• Constant and variable bit rate (MPEG-4)
Image settings • Compression levels: 11 (Motion JPEG) /23 (MPEG-4)
• Rotation: 90º, 180º, 270º
• Aspect ratio correction
• Configurable IR cut filter
• Automatic day/night function
• Backlight compensation, exposure, white balance, brightness, sharpness
• Color and black/white mode
• Overlay capabilities: time, date, text and image
Image sensor ¼" Sony Exview HAD CCD
Lens • Motorized 18x optical zoom lens
• 12x digital zoom
• F1.4 f= 4,1- 73,8mm
• Horizontal viewing angle 2.7° to 48°
• Autofocus
Pan/Tilt/Zoom • Pan: -170° to +170° max speed 100 degrees/s
• Tilt: -30° to +90° max speed 90 degrees/s
• PTZ control queuing capability
Minimum illumination • Color mode: 0.3 lux (30 IRE)
• IR cut filter mode (B/W): 0.005 lux
• With IR lighting (not supplied): 0.0 lux
Security • Multiple user access levels with password protection
• IP address filtering
• HTTPS
Alarm and event
management
• Events triggered by built-in motion detection, external inputs or according
to a schedule
• Image upload over FTP, email and HTTP
• Notification over TCP, email, HTTP and external outputs
• Pre- and post alarm buffer of 6 MB
Connectors • Ethernet 10BaseT/100BaseTX, RJ-45
• 4 -pin I/O Terminal block providing: 1 alarm input, 1output transistors (max
24V, 0.1 A), alternative power input
