AXIS 214 PTZ - Technical Specifications
The AXIS 214 PTZ (PAL) delivers the following file sizes:
PAL PAL aspect ratio corrected
The AXIS 214 PTZ (NTSC) delivers the following file sizes:
Approvals - EMC • EN55022: 1998+A1 class A.
• EN55024: 1998+A1+A2.
• EN61000-6-1: 2001
• EN61000-6-2: 1999
• FCC Part 15, Subpart B, class A. EN 61000-3-2: 2000. EN 61000-3-3: 2000.
• VCCI: 2003, class A.
• C-Tick AS/NZS 3548.
• ICES-003, class A.
Approvals - Safety • UL and cUL (power adapter) EN 60950, GS
• FIMKO (power adapter)
Dimensions
(HxWxD) and weight
• 154 x 143 x 160 mm (6.1” x 5.6” x 6.3”)
• 1.11 kg (2.45 lb) excl. power adapter
MPEG-4 licensing MPEG-4 licenses (1 encoder, 1 decoder) included
Accessories
(not included)
• IP65-rated Dome Housing for installation of camera in outdoor or adverse
indoor environments
• AXIS 292 Network Video Decoder
• AXIS MPEG-4 Decoder 10-user license pack
Applications
(not included)
• AXIS Camera Station - Surveillance application for viewing, recording and
archiving up to 25 cameras
• AXIS Camera Recorder - Surveillance application for viewing and recording
up to 16 cameras
• AXIS Camera Explorer – Basic software for viewing and manual recording
See www.axis.com/partner/adp_partners.htm for more software applications
via partners
Resolution Min-Max (KB) Resolution Min-Max (KB)
4CIF 704x576 10 - 300 4CIF 768x576 11 - 330
2CIF expanded 704x576 10 - 250 2CIF expanded 768x576 11 - 270
2CIF 704x288 5 - 150 2CIF 768x288 5.5 - 160
CIF 352x288 2.5 - 80 CIF 384x288 2.7 - 90
QCIF 176x144 1 - 20 QCIF 192x144 1.1 - 22
NTSC NTSC aspect ratio corrected
Resolution Min-Max (KB) Resolution Min-Max (KB)
4CIF 704x480 8 - 250 4CIF 640x480 7 - 230
2CIF expanded 704x480 8 - 200 2CIF expanded 640x480 7 - 180
2CIF 704x240 4 - 125 2CIF 640x240 3.5 - 110
CIF 352x240 2 - 70 CIF 320x240 1.8 - 60
QCIF 176x120 0.8 - 15 QCIF 160x120 0.7 - 14
