Driver’s Seat
The driver’s seat can be adjusted forward and backward by
pulling the lever located on front left side of the driver’s
seat. Pull lever outward and adjust seat as needed.
Swivel Seat Base
All models are equipped with a swivel seat adjustment.
To adjust the seat, release the lever directly below the
front center of the driver’s seat area by lowering to the
bottom of the seat base. The seat should swivel freely.
To reset the seat position, simply reverse these steps.
Figure 2-10. Bolster Seat
Figure 2-11. Seat Adjuster
Gauges & Controls
2-8
