Engine Specifications
Notes
1) Minimum recorded compression in any one cylinder should not be less than 70% of the highest recorded cylinder.
2) Measured using an accurate shop tachometer at normal operating temperature. Idle RPM on EFI models is not adjustable.
3) Timing must be set using special procedures indicated in the appropriate service manual. Timing cannot be set using
conventional methods. Special tool(s) required.
4) Always use dipstick to determine exact quantity of oil required. Do not fill above “FULL” mark.
5) Do not over fill. Correct level is at the “Full Cold” mark on the coolant recovery bottle when coolant is cold.
Engine Models
AR335 MPI / AR335 ETX/CAT / Raptor 400 / Raptor 400 CAT /
AR335 ETX/CAT Saltwater Raptor 400 CAT Saltwater
2011 Axis Engines
Fluid Capacities
Displacement 350 CID (5.7L) 383 CID (6.3L)
Number of Cylinders V-8
Crankcase (with Filter)
4
5.5 Quarts (5.25L) with Filter
Closed Cooling System
5
12-14 Quarts (11.4-13.3L)
ZF Ski Vee Transmission
4
2.12 Quarts (2L) Main Gearbox, 1.0 Quart (1.06L) V-drive – Dexron 3
Indmar Vee Drive Transmission
2.0 Quarts 10 oz (2.2L) (Front) ATF Dexron 3, Dexron 6 or equivalent,
1.0 Quart 8 oz (1.2L) (Rear) Mobil Del Vac Synthetic Transmission Fluid 50 or equivalent
Spark Plug Gap .060 in. (1.5 mm)
Base Timing at 1000 RPM
3
Nonadjustable
Thermostat 160°F (71°C)
Firing Order 1-8-4-3-6-5-7-2
Spark Plug Type AC 41-932 or 41-993
Electrical System 12 Volt DC Negative (-) Ground
Min. Battery Requirements 650 cca/700 mca/120 Ah
Operating Range at WOT 4600-5200 RPM
Oil Pressure at Idle 4 PSI (41 kPa) Minimum Hot
Oil Pressure at 2000 RPM 18 PSI (124 kPa) Minimum Hot
Idle RPM in Neutral
2
650 ± 50 RPM
Compression Ratio 9.4:1 9.7:1
Compression Pressure
1
Minimum 100 PSI (690 kPa)
4.0012 x 3.480 in. 4.0012 x 3.8 in.
(101.63 x 88.39 mm) (101.63 x 96.52 mm)
Oil Filter Pennzoil PZ3, AC-PF25
Bore/Stroke
Fuel Pump Pressure 60 PSI Minimum at Keyup (414 kPa)
4-5
Care and Maintenance
Chapter 4_11_Axis_ Chapter 4 doc.qxd 12/2/10 9:39 AM Page 5
