Tilt Steering Wheel
The tilt steering wheel allows for maximum driver
comfort. To adjust the height of the wheel, simply press
down on the lever located under the wheel. Move the
wheel to the position that is most comfortable. When the
wheel is in the desired position, simply release the lever to
lock the wheel in place.
Exhaust
The exhaust system is used to remove engine exhaust fumes. To ensure that your boat’s
exhaust system is working correctly, it is important that you inspect for exhaust leaks.
The following information will allow you to check these systems. Keep in mind that you
will be checking engine while turned on, and that you will need to take safeguards against
getting yourself or others caught in the moving parts. Use extreme caution while
performing this task.
• Turn engine off and disconnect the engine safety switch. Be sure the throttle
shift control is neutral. The engine must be cool.
• Open the engine and visually check the exhaust system from the engine to the
transom for obvious damage.
• Reinstall engine safety switch and start the engine with engine compartment open.
Check hose connections between the exhaust manifolds and the muffler for leakage.
• If leakage is apparent, tighten the hose clamps, being careful not to crimp the hose.
See your Axis dealer for parts and or service.
Notice: The AR335 CAT engine equipped with the ETX Catalyst Exhaust
Manifolds may produce an unusual smell which is
characteristic of an engine with a catalyst exhaust system.
Figure 2-24. Tilt Steering
2-13
Gauges & Controls
