Axis AGN/C Series - General Balance Description

6 USER MANUAL
____________________________________________________________________________________________________________________
5. General balance description
Balance view
1 – pan
2 – pan support
3 – pan ring
4 – floor of weighing chamber
5 – keys
6 – rotating legs
7 – water level
8 – LCD display
9 – weighing chamber
Back view
7
6
1
2
8
9
4
5
3
ON
OFF
Adjust switch
RxD(receiver)
TxD(transmitter)
GND
Case
RS232C
Feeder
1
2
3
4
5
6
7
8
9
