5. General balance description
AKA100-AKA520, AKZ100-AKZ520 balances:
1 – pan
2 – pan support
3 – pan ring
4 – display LCD
5 – keys
6 – rotating legs
7 – water level
8 – draft shield
AKA1200-AKA4200 , AKZ1200-AKZ10 balances:
1 – pan
2 – nuts (under pan)
4 – LCD display
5 – keys
6 – rotating legs
7 – water level
7
6
1
2
4
5
7
6
1
2
4
3
5
8
