Axis AX-902 - Function of Controls; Position of Controls

4
FUNCTION OF CONTROLS
1. POWER ON/OFF ( )
2. FUNCTION SELECT BUTTON: BASS/TREBLE/BALANCE/FADER/AUDIO DSP/
LOUDNESS/SUBWOOFER/ESP/CD MULTI/SCROLL/BEEP/STEREO/LOCAL/PAIRING
3. VOL UP/VOL DOWN FOR BASS/TREBLE/BALANCE/FADER/AUDIO DSP/
LOUDNESS/SUBWOOFER/ESP/CD MULTI/SCROLL/BEEP/STEREO/LOCAL/PAIRING
4. PRESET STATIONS (1,2,3,4,5,6)
5. MUTE BUTTON (MU)
6. LOCAL/DISTANT BUTTON (LOC)
7. EQUALIZER CONTROL (EQ)
8. STEREO/MONO BUTTON (ST)
9. DISPLAY BUTTON (DISP)
10. MODE BUTTON (MODE)
11. BAND BUTTON (BND)
12. AUTOMATIC OR MANUAL TUNING (FREQ UP
OR FREQ DOWN /
CD TRACK/SEARCH BUTTON
13. AUTO SEEK SEARCH TUNING (A/PS)
14. ‘SCAN’ AUTOMATIC TUNING CONTROL (SCN)
15. LCD DISPLAY
16. PANEL RELEASE BUTTON (
)
17. CD SLOT
18. CD EJECT BUTTON (
)
19. TOP BUTTON (TOP)
20. PAUSE BUTTON (BND)
21. INTRO BUTTON (Preview all Tracks) (INT)
22. REPEAT BUTTON (A/PS)
23. RANDOM BUTTON (RDM)
24/ 25. + 10 TRACK SEARCH DOWN/UP
26. AUX IN
27. USB PORT
POSITION OF CONTROLS
(CAR STEREO)
MP3
(1-6)
4
1 15 1322 7 16 11 20 271423
9 19 21 23 24 25 8 5 6 261012
18 17
MP3
MP3
(1-6)
4
1 15 1322 7 16 11 20 271423
9 19 21 23 24 25 8 5 6 261012
18 17
MP3
