Axis F34 User Manual

AXISF34MainUnit
Video
Youcanaddanewmask,re-sizethemaskwiththemouse,chooseacolorforthemask,andgivethemaskaname.
Formoreinformation,seetheonlinehelp
Important
Addingmanyprivacymasksmayaffecttheproduct’sperformance.
Note
Privacymaskisnotavailableforthequadstream.However,privacymasksconguredoneachchannelwillbedisplayed
inthequad.
StreamProles
Astreamproleisasetofpredenedstreamsettingsincludingresolution,compression,framerateandoverlaysettings.Stream
prolescanbeused:
•Whensettinguprecordingusingactionrules.SeeEventsonpage36.
•Whensettingupcontinuousrecording.SeeContinuousRecordingonpage4
1.
•
IntheLiveViewpage–selectthestreamprolefromtheStreamproledrop-downlist.
Forquicksetup,useoneofthepredenedstreamproles.Eachpredenedprolehasadescriptivename,indicatingitspurpose.If
required,thepredenedstreamprolescanbemodiedandnewcustomizedstreamprolescanbecreated.
Tocreateanewproleormodifyanexistingprole,gotoSetup>Video>StreamProles.
ToselectadefaultstreamprolefortheLiveViewpage,gotoSetup>LiveViewCong.
ONVIFMediaProles
AnONVIFmediaproleconsistsofasetofcongurationsthatcanbeusedtochangemediastreamsettings.ONVIFmediaproles
canbesetthroughtheONVIFMediaProleSettingspageandbeusedbyaclienttoconguremediastreamproperties.
TheONVIFMediaProlespagelistsallsuchpre-conguredproles.Theseprolescannotberemoved.Pre-conguredmedia
proleshavebeenincludedintheproductforquicksetup.ItisalsopossibletocongurenewONVIFmediaprolesasperrequired
specications.ToaddanewONVIFmediaprole,clickAddandentertherequiredinformation.Youcanalsomodifyorremovea
prolefromthispage.
ImageSynchronization
Itispossibletosynchronizetwoormoresensorunitsintermsofframesandexposure.
Framesynchronizationisautomaticinthecaseofidenticalsensorunitsthathavethesamecapturemode.
TosynchronizeexposuregotoVideo>ImageSynchronization.UnderExposuresynchronizationitispossibletogroupthecameras
asoneortwogroups.WithineachgroupthecamerathatisselectedrstbecomestheMasterandtheothercamerassynchronize
theirexposuresaccordingly.
Overlay
Overlaysareusedtoprovideextrainformation,suchasforensicvideoanalysisorduringproductinstallationandconguration.
Overlaysaresuperimposedoverthevideostream.
Anoverlaytextcandisplaythecurrentdateandtime,oratextstring.
Whenusingatextstring,modierscanbeusedtodisplayinformationsuchasthecurrentbitrateorthecurrentframerate.
23

Axis F34 Specifications

General

Product color	Multicolor
Color	-
LED type	IR
Sensor type	CMOS
Camera included	No
Housing material	Plastic, Zinc
Number of cameras	4
Placement supported	Indoor
Minimum illumination	0.4 lx
Connectivity technology	Wired
Horizontal rotation angle	- °
Surveillance camera form factor	Dome
Flash memory	256 MB
Internal memory	1024 MB
Channels quantity	4 channels
Recorder included	Yes
Storage media type	Flash
Total storage capacity	256 GB
Compatible memory cards	SD, SDHC, SDXC
Display diagonal	- \
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Camera weight	96 g
Recorder width	121 mm
Recorder height	30 mm
Recorder weight	238 g
