AXISF44DualAudioInput
7.Ifrequired,attachtheRS232cabletoconnecttoauxiliary
equipment.
ShortenSensorUnitCable
Note
•Thesensorunitcablecannotbeextendedorsplit.
•Whenroutingthesensorunitcable,theminimumbending
radiusis40mm.
Thesensorunitisdeliveredwithacable.Toshortenthecablefollow
thesesteps:
1.Cutthecabletothedesiredlength.Measurefromthesensor
unit.
2.Striptheplasticoutercoatingfromtheendofthecable.
3.Peelbacktheshield.
4.Flattenthecoloredwiresintheorderdescribedbelow.
1
Brown
2
White/brown
3
Notused
4
Notused
5
White/blue
6
Blue
5.Insertthewiresallthewayintoashielded6P6CRJ12
connector.
