AXISM1013NetworkCamera
Video
1.GotoVideo>VideoStreamandselecttheImagetab.
2.UnderOverlaySettings,selectIncludetext.
3.Enterthemodier#Dand,optionally,additionaltextwhichwillbedisplayedalsowhentheactionruleisnotactive.
Createtheactionrule:
1.GotoEvents>ActionRules
2.ClickAddtocreateanewrule.
3.SelectaTriggerand,optionally,aScheduleandAdditionalconditions.Seetheonlinehelpfordetails.
4.FromtheActionslist,selectOverlayText
5.EnterthetexttodisplayintheTexteld.Thisisthetextthat#Dwillbereplacedby.
6.SpecifytheDuration.Thetextcanbedisplayedwhiletheruleisactiveorforaxednumberofseconds.
Example
Todisplaythetext“Motiondetected”whenmotionisdetected,enter#DintheIncludetexteldandenter“Motiondetected”in
theTexteldwhensettinguptheactionrule.
PrivacyMask
Aprivacymaskisauser-denedareathatpreventusersfromviewingpartsofthemonitoredarea.Privacymasksappearasblocks
ofsolidcolorandareappliedonthevideostream.PrivacymaskscannotbebypassedusingtheVAPIX®applicationprogramming
interface(API).
ThePrivacyMaskList(Video>PrivacyMask)showsallthemasksthatarecurrentlyconguredintheAxisproductandindicates
iftheyareenabled.
Youcanaddanewmask,re-sizethemaskwiththemouse,chooseacolorforthemask,andgivethemaskaname.
Formoreinformation,seetheonlinehelp
Important
Addingmanyprivacymasksmayaffecttheproduct’sperformance.
21

Axis M1013 Specifications

General

Maximum resolution	800 x 600 pixels
Supported video modes	-
Camera shutter speed	1/6 - 1/8000 s
Minimum illumination	1.2 lx
Field of view (FOV) angle	67 °
Sensor type	CMOS
Progressive scan	Yes
Optical sensor size	1/4 \
Optical zoom	- x
Focus adjustment	2.0
Built-in HDD	No
Flash memory	128 MB
Internal memory	256 MB
Type	IP security camera
Certification	EN 55022 Class B, EN 61000-3-2, n EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, EN 55024, FCC Part\\r 15 Subpart B and C Class B, VCCI Class B, C-tick AS/NZS CISPR 22, ICES-003 Class B, KCC Class B, IEC/EN 60950-1
Placement supported	Indoor
Connectivity technology	Wired
Form factor	Box
Mounting type	Ceiling/wall
Product color	White
Housing material	Polycarbonate (PC)
Protection features	Dust resistant, Scratch resistant
Bundled software	VAPIX
Interface	RJ-45
Ethernet LAN (RJ-45) ports	1
Cabling technology	10/100Base-T(X)
Supported network protocols	IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
DC output voltage	+5V
Power consumption (typical)	2.2 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	95 mm
Width	59 mm
Height	41 mm
Weight	110 g
