Axis M1054 Installation Guide

Page 10 AXIS M10 Series
Assign an IP address
Most networks today have a DHCP server that automatically assigns IP
addresses to connected devices. If your network does not have a DHCP
server, the Network Camera will use 192.168.0.90 as the default IP
address.
AXIS IP Utility and AXIS Camera Management are the recommended
methods for setting an IP address in Windows. These free applications
are available on the Axis Network Video Product CD supplied with this
product, or they can be downloaded from www.axis.com/techsup
Depending on the number of cameras you wish to install, use the
method that suits you best.
Notes:
• If assigning the IP address fails, check that there is no firewall blocking the
operation.
• For other methods of assigning or discovering the IP address of the AXIS M10
Series, such as in other operating systems, see page 19.
Method Recommended for Operating system
AXIS IP Utility
See page 11
Single camera
Small installations
Windows
AXIS Camera
Management
See page 12
Multiple cameras
Large installations
Installation on a different
subnet
Windows 2000
Windows XP Pro
Windows 2003 Server
Windows Vista

Axis M1054 Specifications

General

Max Resolution	1280x800
Operating Temperature	0 °C to 50 °C (32 °F to 122 °F)
Day/Night	No
Humidity	20-80% RH (non-condensing)
Image Sensor	1/4" progressive scan RGB CMOS
Resolution	1280x800
Lens	2.8 mm, F2.0
Video Compression	H.264, Motion JPEG
Frame Rate	30 fps in all resolutions
Audio	Two-way audio with built-in microphone and speaker
Audio Compression	AAC LC 8/16 kHz, G.711 PCM
Network	10/100 Mbps Ethernet
Power	Power over Ethernet (PoE) IEEE 802.3af
Power Consumption	Max 3.8 W
