Axis M1054 User Manual

13
AXIS M10 Series - Accessing the Camera
Note:
In Simplex – speaker only or microphone only mode, you can use either the Microphone button or the half-duplex
Talk button to stop sending audio to the network camera. To send audio, both buttons must be enabled.
Click the Microphone button to switch the sound off and on to your computer's microphone.
In Simplex - Network Camera speaker only mode, you can click this button to stop sending audio to the network
camera. See note below.
Use this slider to control the volume of the speakers and the microphone.

Axis M1054 Specifications

General

Max Resolution	1280x800
Operating Temperature	0 °C to 50 °C (32 °F to 122 °F)
Day/Night	No
Humidity	20-80% RH (non-condensing)
Image Sensor	1/4" progressive scan RGB CMOS
Resolution	1280x800
Lens	2.8 mm, F2.0
Video Compression	H.264, Motion JPEG
Frame Rate	30 fps in all resolutions
Audio	Two-way audio with built-in microphone and speaker
Audio Compression	AAC LC 8/16 kHz, G.711 PCM
Network	10/100 Mbps Ethernet
Power	Power over Ethernet (PoE) IEEE 802.3af
Power Consumption	Max 3.8 W
