Axis M1054 User Manual

6
AXIS M10 Series - Product Description
Overview
PIR Sensor - AXIS M1031-W/AXIS M1054 is equipped with a PIR Sensor that has a maximum range of 6 meters for detecting
movement in the dark.
Light - White LED to illuminate the scene.
Microphone/Speaker - Two-way audio support allows for remote users to listen in on an area and communicate with visitors
or intruders.
Power Connector - For connection of the PS-H or PS-V power adapter (included).
Network Connector - The camera connects to the network via a standard network connector. Supporting NWay, the camera
detects the speed of the local network segment (10BaseT/100BaseTX Ethernet).
Serial Number Label - The serial number may be required during installation.
Control Button - Press this button to install the camera using the AXIS Internet Dynamic DNS Service, or to restore the
factory default settings, as described in
Resetting to the Factory Default Settings, on page 42.
Note:
AXIS Internet Dynamic DNS Service is a free service from Axis that allows you to quickly and easily install your camera.
This requires an Internet connection with no HTTP proxy. See www.axiscam.net for more information.
Product number (P/N) &
The serial number may be
required during the installation.
Power connector
Control button
Network connector
Power Indicator LED
Network Indicator LED
Lock ring
Microphone
Light
PIR
Wireless Indicator LED
(activated on wireless models only)
Speaker
AXIS M1031-W/AXIS M1054
AXIS M1011/-W
Rear view (all models)
Lens with
Status Indicator
LED
Front view -
sensor
Serial number (S/N).
Lens
I/O connector
(AXIS M1054 only)

Axis M1054 Specifications

General

Max Resolution	1280x800
Operating Temperature	0 °C to 50 °C (32 °F to 122 °F)
Day/Night	No
Humidity	20-80% RH (non-condensing)
Image Sensor	1/4" progressive scan RGB CMOS
Resolution	1280x800
Lens	2.8 mm, F2.0
Video Compression	H.264, Motion JPEG
Frame Rate	30 fps in all resolutions
Audio	Two-way audio with built-in microphone and speaker
Audio Compression	AAC LC 8/16 kHz, G.711 PCM
Network	10/100 Mbps Ethernet
Power	Power over Ethernet (PoE) IEEE 802.3af
Power Consumption	Max 3.8 W
