AXIS M10 Series - Video & Audio Settings
Video & Audio Settings
This section describes how to configure the camera, and is intended for product Administrators, who have unrestricted access
to all settings; and Operators, who have access to the settings for Basic Setup, Video & Audio and Events.
You can configure the camera by clicking Setup in the top right-hand corner of the Live View page. Click on this page to
access the online help that explains the configuration menus.
Video Stream
The video stream settings appear under four
different tabs:
•Image
• Audio (AXIS M1031-W and AXIS
M1054)
• MPEG-4 & H.264
•MJPEG
Note:
AXIS M1054 does not support MPEG-4.
Image Appearance
Use these settings to modify the image resolution and compression. Setting the compression level affects the image quality
and the amount of bandwidth required; the lower the compression, the higher the image quality with higher bandwidth
requirements.
Mirroring (AXIS M1054 and AXIS M1031-W only) - Mirroring is the horizontal flipping of an image, that gives you
another image perspective. This is a useful function when you need a direct view of the image, for example, in ATMs and door
phones. Define mirroring settings before defining parameters for privacy masks and motion detection.
Rotate image - The image can be rotated by selecting one of the available values.
See the online help for more information.
Video Stream
To avoid bandwidth problems on the network, the frame rate allowed to each viewer can be limited. Select the Unlimited
radio button option to allow the highest available frame rate; or select the Limited to radio button option and enter a value
(1-30) fps in the field.
