AXIS M10 Series - Technical Specifications
General
Processors, memory AXIS M1011, AXIS M1011-W, AXIS M1031-W
ARTPEC-B, 64 MB RAM, 32 MB Flash
AXIS M1054
ARTPEC-3, 128 MB RAM, 128 MB Flash
Power 4.9 – 5.1 V DC max. 7.5 W
AXIS M1054
Power over Ethernet IEEE 802.3af Class 1
Connectors DC jack
AXIS M1011, AXIS M1011-W, AXIS M1031-W
RJ-45 10BASE-T/100BASE-TX Auto-MDIX
AXIS M1054
RJ-45 10BASE-T/100BASE-TX PoE, DC jack, 1 alarm input and 1 output
PIR Sensor (AXIS
M1031-W and AXIS
M1054)
Passive infrared (PIR) motion sensor with configurable sensitivity. Max
range: 6 m
Illumination LED
(AXIS M1031-W and
AXIS M1054)
White illumination LED: 1 W
Operating conditions Humidity 20 - 80% RH (non-condensing)
AXIS M1011, AXIS M1011-W, AXIS M1031-W
0 – 50 ºC (32 – 122 ºF)
AXIS M1054
0 – 40 ºC (32 – 104 ºF)
Approvals • AXIS M1011:
EN 55022 Class B, EN 55024, EN 61000-3-2, EN 61000-3-3, EN
60950-1, FCC Part 15 Subpart B Class B, VCCI Class B, ICES-003 Class
B, C-tick
• AXIS M1011-W and AXIS M1031-W:
EN301489-1, EN301489-17, EN300328, EN 60950-1, FCC Part 15
Subpart B and C Class B, RSS-210, C-TICK, TELEC, KCC, SRRC
• AXIS M1054
EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 55024, FCC Part
15 Subpart B Class B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS
CISPR 22, KCC Class B, EN 60950-1
• Power supply:
EN 60950-1, cCSAus
Dimensions (HxWxD) 28 x 59 x 95 mm (1.1"x2.3"x3.7")
Weight • AXIS M1011: 94 g (0.207 lb)
• AXIS M1011-W: 94 g (0.207 lb)
• AXIS M1031-W: 101 g (0.222 lb)
• AXIS M1054: 156 g (0.344 lb)
Included accessories Power supply, stand and clamp, Installation Guide, CD with installation
tools, recording software and User’s Manual, Windows decoder 1-user
license
AXIS M1054: Extension to stand
Optional accessories Extension to stand
Video management
software
(not included)
AXIS Camera Station - Video management software for viewing and
recording up to 50 cameras. See
www.axis.com/products/video/software/ for more software
applications via partners
Function/group Item Specification
