AXISP12NetworkCameraSeries
AngledSurfaceInstallation
1.Fastentheangledmountingbrackettothewallorceiling,usingscrewsandplugs
appropriateforthewall/ceilingmaterial.Ensurethatthebracketispointingtowards
theareatobemonitored.
2.Assembletheplatewiththescrewandalignitsothearrowsareverticalorhorizontal.
3.Fastenthecameratotheplatewiththetwoscrews.
4.Snaponthecover.
5.ProceedtoConnectthecables,seeConnecttheCablesonpage24.
19
