AXISP1214NetworkCamera
HardwareOverview
1.Cutthecabletothedesiredlength.Measurefromthesensorunit.
2.Striptheplasticoutercoatingfromtheendofthecable.
3.Peelbacktheshield.
4.Flattenthecoloredwiresintheorderdescribedbelow.
1
Brown
2
White/brown
3
Notused
4
Notused
5
White/blue
6
Blue
5.Insertthewiresallthewayintoashielded6P6CRJ12connector.Makesurethatthewiresstayinthecorrectorder.
6.Useacrimpingtooltofastentheconnectortothecable.
14 mm 14 mm
6
1
6
