Page 8 AXIS P13-E Network Camera Series Installation Guide
Install the hardware
The instructions below describe the installation of AXIS P1343-E/P1344-E/P1346-E/P1347-E.
Install the wall bracket
1. Use the supplied drill template to prepare a wall, ceiling, or pole for installation of the wall
bracket.
2. Route the network cable through the wall bracket and the bracket adapter. Leave
approximately 30 cm (11.8”) of cable for connecting the camera.
3. Install the wall bracket on a wall, ceiling, or pole and make sure that the screws and plugs are
appropriate for the material (e.g. wood, metal, sheet rock, stone).
Notes:
• The weight of the camera is shown in the table below. Check that the material is strong enough to
support this weight.
• For more technical specifications, please see the User’s Manual, available on the CD included in this
package, or from www.axis.com
Model Weight
AXIS P1343-E 3090 g (6.8 lb.)
AXIS P1344-E 3120 g (6.9 lb.)
AXIS P1346-E 3130 g (6.9 lb.)
AXIS P1347-E 3.200 g (7.2lb.)
