AXISP1445-LE-3LicensePlateVerifierKit
Getstarted
4.0m(13ft)2.0m(6.6ft)
5.0m(16ft)2.5m(8.2ft)
7.0m(23ft)3.5m(1 1ft)
Freeowcapturedistance:7–20m(23–65ft).ThisexampleisbasedontheAXISP1455–LE-3LicensePlateVerierkit.
Capturedistance(x)Mountingheight(y)
7.0m(23ft)3.0m(9.8ft)
10.0m(33ft)4.0m(13ft)
15.0m(49ft)6.0m(19.5ft)
20.0m(65ft)10.0m(33ft)
•Thecamera’smountingangleshouldnotbelargerthan30°inanydirection.
Mountinganglefromtheside.
5
