Axis P3343 Installation Guide

Page 6 AXIS P33 Network Camera Series Installation Guide
Hardware overview
Dimension (HxW)
AXIS P3343/AXIS P3344 = 97 x 148 mm (3.8” x 5.8”)
AXIS P3343-V /AXIS P3344-V = 97 x 148 mm (3.8” x 5.8”)
AXIS P3346 = 101 x 148 mm (4” x 5.83”)
AXIS P3346-V = 104 x 148 mm (4.07” x 5.83”)
AXIS P3367-V = 104 x 148 mm (4.07” x 5.83”)
Weight
AXIS P3343/AXIS P3344 = 445 g (1.0 lb)
AXIS P3343-V/AXIS P3344-V = 660 g (1.5 lb)
AXIS P3346 = 490 g (1.1 lb)
AXIS P3346-V = 700 g (1.53 lb)
AXIS P3367-V = 700 g (1.53 lb)
Network connector
LED indicators
Control button
I/O connector
(PoE)
Camera unit
Network cable
Dome cover
out
Audio
in
SD memory card slot
Wall screws
Audio
Camera unit
Fan output
connector
Built-in microphone

Axis P3343 Specifications

General

Maximum frame rate	30 fps
Maximum video resolution	800 x 600 pixels
Built-in microphone	Yes
I/O ports	1 x Ethernet
Compatible memory cards	SD, SDHC
Compliance industry standards	IEEE 802.3af
