Axis P5414-E - Connectors

AXISP5414-EPTZDomeNetworkCamera
TechnicalSpecifications
AXIST94P01BCornerBracket
AXIST98A19-VESurveillanceCabinet
Video
management
software
AXISCameraCompanion,AXISCameraStation,VideomanagementsoftwarefromAxis’ApplicationDevelopment
Partnersavailableonwww.axis.com/techsup/software
Languages
English,German,French,Spanish,Italian,Russian,SimpliedChinese,Japanese,Korean,Portuguese
Warranty
Axis3-yearwarrantyandAXISExtendedWarrantyoption,seewww.axis.com/warranty
a.Withcorner-mountinstallations,thereisslightvisualobstructionfromthehousingintheupperleft/rightcorneroftheimageat
panendpoints.
b.ThisproductincludessoftwaredevelopedbytheOpenSSLProjectforuseintheOpenSSLToolkit.(www.openssl.org),and
cryptographicsoftwarewrittenbyEricYoung(eay@cryptsoft.com).
Moreinformationisavailableatwww.axis.com
Connectors
I/OTerminalConnector
6–pinterminalblockfor:
•DigitalInput
•DigitalOutput
•0VDC(-)
1 2 3 4 5 6
FunctionPinNotes
Specications
0VDC(-)
1
0VDC
DCoutput
2
Canbeusedtopowerauxiliaryequipment.
Note:Thispincanonlybeusedaspowerout.
12VDCPower
Maxload=50mA
Digitalinput–Connecttopin1toactivate,orleaveoating
(unconnected)todeactivate.
0to+30VDC Congurable
(InputorOutput)
3–6
Digitaloutput–Connectedtopin1whenactivated,oating
(unconnected)whendeactivated.Ifusedwithaninductive
load,e.g.arelay,adiodemustbeconnectedinparallelwith
theload,forprotectionagainstvoltagetransients.
Maxload=100mA
Maxvoltage=+30VDC
67
