Axis P5414-E User Manual

AXISP5414-EPTZDomeNetworkCamera
HardwareOverview
HardwareOverview
4
3
2
1
5
6
7
8
1
Controlbutton
2
StatusLEDindicator
3
SDmemorycardslot
4
Audioconnector
5
I/Oconnector
6
Powerconnector
7
Networkconnector(PoE+)
8
Partnumber(P/N)&Serialnumber(S/N)
ConnectorsandButtons
Fortechnicalspecications,seepage65.
NetworkConnector
RJ45EthernetconnectorwithPoweroverEthernetPlus(PoE+).
NO NO
NO
TICE TICE
TICE
Theproductshallbeconnectedusingashieldednetworkcable(STP).Allcablesconnectingtheproducttothenetworkshall
beintendedfortheirspecicuse.Makesurethatthenetworkdevicesareinstalledinaccordancewiththemanufacturer’s
instructions.Forinformationaboutregulatoryrequirements,seeElectromagneticCompatibility(EMC)onpage2.
