Axis P5635-E Mk II - Axis 10-Pin Push-Pull System Connector (Sold Separately)

AXISP5635-EPTZMkIIDomeNetworkCamera
TechnicalSpecifications
FunctionPinNotes
Specications
DCOutput
2
Canbeusedtopowerauxiliaryequipment.
Note:Thispincanonlybeusedaspowerout.
12VDC
Maxload=50mA
GND
1
Ground
Digitalinput–Connecttopin8toactivate,orleave
oating(unconnected)todeactivate.
0tomax30VDC Congurable
(InputorOutput)
3–I/O1
4–I/O2
5–I/O3
6–I/O4
Digitaloutput–Connectedtopin8whenactivated,
oating(unconnected)whendeactivated.Ifusedwithan
inductiveload,e.g.arelay,adiodemustbeconnected
inparallelwiththeload,forprotectionagainstvoltage
transients.
0tomax30VDC,opendrain,
100mA
1
GND
2
DCoutput12V,max50mA
A
I/Oconguredasinput
B
I/Oconguredasoutput
Axis10-pinPush-PullSystemConnector(soldseparately)
WhenconnectingexternalequipmenttotheAxisproduct,anAxis10-pinPush-PullSystemConnector(soldseparately)isrequiredin
ordertomaintaintheproduct’sIPrating.
Mountingthewiresrequiresacrimptool.Fordetailedmountinginstructionsofthewires,visitAxisSupportatwww.axis.com/techsup/.
Connectthe10-pinPush-PullSystemConnectortotheproduct’smulti-connector.Tolocatethemulti-connector,seeHardware
Overviewonpage7.
