Axis P5635-E Mk II - Hardware Overview

To Next Page

To Previous Page

AXISP5635-EPTZMkIIDomeNetworkCamera

HardwareOverview

Forspecicationsofthehardwarecomponents,seeTechnicalSpecicationsonpage67.

NO NO

TICE TICE

TICE

Makesurethedomeisattachedinoperationmode,otherwisefocusmaybeaffected.

Groundscrew

Mountingscrews(3)

Networkconnector(PoE+)

Multi-connectorwithcover(DonotremovethecoverunlessanI/O-cableisconnected)

Hookforsafetywire

SDmemorycardslot

Controlbutton

StatusLEDindicator

Powerbutton

Dome
